National Item Identification Number
01-171-5386
011715386
5365-01-171-5386
5365011715386
National Stock Number
Item Name
SPACER,RING
Federal Supply Class
5365
Referenced on: http://constructioncranes.tpub.com//TM-5-3810-303-24P/css/TM-5-3810-303-24P_450.htm
Referenced on: http://constructioncranes.tpub.com//TM-5-3810-303-24P/css/TM-5-3810-303-24P_508.htm
Referenced on: http://constructioncranes.tpub.com//TM-5-3810-303-24P/css/TM-5-3810-303-24P_631.htmDescription
A circular-shaped item designed to maintain predetermined distance between assembled parts and/or for distributing pressure or preventing endwise movement between member parts. It has a solid cross-section and two flat parallel bearing surfaces. The distance between the bearing surfaces perpendicular to the axis of the centrally located hole shall not exceed 25 percent of the outside diameter. The diameter of the centrally located hole must exceed 75 percent of the outside diameter. Excludes laminated items. For items manufactured from impregnated graphite or lubricated nonmetallic materials, excluding felt or plastics, see GASKET. For items manufactured from lubricated plastics, see BEARING, WASHER, THRUST. For items manufactured from lubricated felt, see FELT, MECHANICAL, PREFORMED. Excludes DISK, VALVE; INSULATOR WASHER; and SHIM. See also SPACER, PLATE and SPACER, SLEEVE.
Commercial and Government Entity Code (Supplier Data)
27315
SPH CRANE & HOIST INC
DBA MORRIS MATERIAL HANDLING
315 W FOREST HILL AVE
OAK CREEK
WI
53154
414-764-8572
NSN (National Stock Number) 5365-01-171-5386, 5365011715386 NIIN (National Identification Number) 01-171-5386, 011715386
Part Numbers (Reference Numbers)
218T389
Required Categories
MATERIAL
OVERALL THICKNESS
INSIDE DIAMETER
OUTSIDE DIAMETER
SPECIAL FEATURES
Required Description
STEEL
1.235 INCHES MINIMUM AND
1.250 INCHES MAXIMUM
4.740 INCHES MINIMUM AND;
